ALDERON FLAT WALL PANEL
Alderon Flat Wall Panel merupakan produk inovatif dari PT. Unipack Plasindo yang menggabungkan sifat tahan terhadap bahan kimia, mereduksi panas, anti bocor, bobot yang ringan; dan mudah untuk dipasang maupun dilapisi dengan lapisan dekoratif.
Alderon Flat Wall Panel terbuat dari material uPVC yang secara khusus dikembangkan untuk tahan terhadap radiasi sinar UV serta hadir dengan inovasi desain yang memperkuat dan meningkatkan kualitasnya.
Keunggulan Alderon Flat Wall Panel
Tahan Terhadap Bahan Kimia
Mereduksi Panas
Anti Bocor
Bobot yang Ringan
Flat Wall
Panel
Alderon Flat Wall Panel (FWP) merupakan salah satu produk inovatif dari PT. Unipack Plasindo yang menggabungkan sifat tahan terhadap bahan kimia, mereduksi panas, anti bocor, bobot yang ringan; dan mudah untuk dipasang atau dikustomisasi dengan lapisan motif dekoratif. Selain itu, Alderon FWP hadir dengan sifat menghambat perambatan api yang memenuhi standar internasional. Dilengkapi dengan sifat dapat memadamkan api sendiri tanpa sumber api eksternal.
Product Specifications
| Effective Width | 1000 mm |
| Weight | 5.7 Kg/Lm |
| Flat Thickness | 20 mm |
Some examples of Alderon FWP uses
- Industrial & Commercial building wall panels.
- Portable partitions panels for temporary rooms.
- Clean Food & Pharmaceutical factories panels.
- Emergency housing/building panels.
- Animal farms insulating & chemical resistant (vs animal waste)wall claddings.
Thermal Properties
| Test Method | Product Alderon FWP | |
| Thermal Conductivity | ASTM E1530-11 | 0.27 W/mk |
| Thermal Resistance | ASTM E1530-11 | 7.13E-2 m2k/w |
| Service Temperature | -20 to 60 degree Celcius |
Alderon FWP being of hollow and triple walled construction is of good thermal (and sound) insulating properties. Above are tested sample data of insulating and conducting properties for comparison with other walls
and panels.
The service temperature range of Alderon FWP is -20°C to 60 °C, greater care should be taken when working with UPVC Sheet at lower temperatures; UPVC is less resistant to impact damage at temperatures below zero
Celsius.
Flammability
Alderon FWP is self-extinguishing without external flame source and conforms with the highest ratings for plastic and composite materials. Under UL94 Flammability Test, Alderon FWP classified as V-0 low flammability.
Physical & Mechanical Properties
| Test Method | Product Alderon FWP | |
| Tensile Strength at Yield | ASTM D-638 | 30 Mpa |
| Elongation at Yield | ASTM D-638 | 15% |
| Hardness | ASTM D-2240 | 79 |
| Modulus of Elasticity in Bending | ASTM D-790 | 750 |
When installing Alderon FWP, horizontal supporting beams should be applied for every 1500 mm – 1800 mm of height and vertical beam for approximately 2000 mm span width.
Please take note that mechanical strength would reduce over time if exposed to sunlight and chemicals, and it is recommended after some years (depending on the location environment) that inspections be carried out
re the structural integrity of the panels.
Corrosion and Chemical Resistance
| Test Method | Product Alderon FWP | |
| Sulphuric Acid 40% 60 degree Celcius 168 hours | ASTM D543-06 | No Change |
| Nitric Acid 40% 60 degree Celcius 168 hours | ASTM D543-06 | No Change |
| Ammonia Gas room temperature 168 hours | ASTM D543-06 | No Change |
Alderon FWP has good chemical resistance to a wide range of chemicals , acids and bases, especially rubber processing chemicals, paper making chemicals, animal and waste farms methane & ammonia gas/vapour,
fertilizer chemicals, galvanizing fumes etc.
Installation Process
- Install the cladding module to the structure using roofing screws.
- Attach the second cladding module from male to female with the tongue & groove system.
- Repeat the step to install the next module.
- + Product Specifications
-
Product Specifications
Effective Width 1000 mm Weight 5.7 Kg/Lm Flat Thickness 20 mm Some examples of Alderon FWP uses
- Industrial & Commercial building wall panels.
- Portable partitions panels for temporary rooms.
- Clean Food & Pharmaceutical factories panels.
- Emergency housing/building panels.
- Animal farms insulating & chemical resistant (vs animal waste)wall claddings.
- + Thermal Properties
-
Thermal Properties
Test Method Product Alderon FWP Thermal Conductivity ASTM E1530-11 0.27 W/mk Thermal Resistance ASTM E1530-11 7.13E-2 m2k/w Service Temperature -20 to 60 degree Celcius Alderon FWP being of hollow and triple walled construction is of good thermal (and sound) insulating properties. Above are tested sample data of insulating and conducting properties for comparison with other walls
and panels.The service temperature range of Alderon FWP is -20°C to 60 °C, greater care should be taken when working with UPVC Sheet at lower temperatures; UPVC is less resistant to impact damage at temperatures below zero
Celsius. - + Flammability
-
Flammability
Alderon FWP is self-extinguishing without external flame source and conforms with the highest ratings for plastic and composite materials. Under UL94 Flammability Test, Alderon FWP classified as V-0 low flammability.
- + Physical & Mechanical Properties
-
Physical & Mechanical Properties
Test Method Product Alderon FWP Tensile Strength at Yield ASTM D-638 30 Mpa Elongation at Yield ASTM D-638 15% Hardness ASTM D-2240 79 Modulus of Elasticity in Bending ASTM D-790 750 When installing Alderon FWP, horizontal supporting beams should be applied for every 1500 mm – 1800 mm of height and vertical beam for approximately 2000 mm span width.
Please take note that mechanical strength would reduce over time if exposed to sunlight and chemicals, and it is recommended after some years (depending on the location environment) that inspections be carried out
re the structural integrity of the panels. - + Corrosion and Chemical Resistance
-
Corrosion and Chemical Resistance
Test Method Product Alderon FWP Sulphuric Acid 40% 60 degree Celcius 168 hours ASTM D543-06 No Change Nitric Acid 40% 60 degree Celcius 168 hours ASTM D543-06 No Change Ammonia Gas room temperature 168 hours ASTM D543-06 No Change Alderon FWP has good chemical resistance to a wide range of chemicals , acids and bases, especially rubber processing chemicals, paper making chemicals, animal and waste farms methane & ammonia gas/vapour,
fertilizer chemicals, galvanizing fumes etc. - + Installation Process
-
Installation Process
Click image to enlarge - Install the cladding module to the structure using roofing screws.
- Attach the second cladding module from male to female with the tongue & groove system.
- Repeat the step to install the next module.
